Create Donut chart using Svg and D3 in React Native

What is Donut Chart?

A donut chart is a type of data visualization that is similar to a pie chart but with a hole in the center. It’s essentially a ring divided into sections, where each section represents a proportion of the whole data set. Donut charts are useful for displaying categorical data and comparing the sizes of different categories.

Lets create a simple donut chart in React Native:

First create a component called donut

How I prefer to create components

– components

– – charts

– – – donut

– – – – index.tsx

– – – – donut.test.ts

We will make another story for the best folder structure for most type of the type of projects

First of all create component for Donut chart:

import React, { useMemo, memo } from “react”;
import { View, StyleSheet } from “react-native”;

const Donut = () => {

  const component = () => (
    <View style={styles.wrapper}>

    </View>
  );

  return useMemo(component, dependancies)
}

export default memo(Donut);

const styles = StyleSheet.create({
   wrapper: {}
})

Then, import Donut component in the App.js

import React from “react”;
import { Donut } from “@componnets/charts”;
import donutData from “@data/donut.json”

const App = () => <Donut data={donutData} />;

export default App;

Now install svg and d3 packages

• yarn add react-native-svg d3

Then run,

• yarn pod

Now we are ready to create Donut chart 😃

• Prepare json data for the chart and convert that data into pie data using d3 for arc

const donutData = [
  {
    id: 1,
    title: ‘first’,
    value: 7,
    color: randomColor(),
  },
  {
    id: 2,
    title: ‘second’,
    value: 50,
    color: randomColor(),
  },
  {
    id: 3,
    title: ‘third’,
    value: 13,
    color: randomColor(),
  },
  {
    id: 4,
    title: ‘fourth’,
    value: 20,
    color: randomColor(),
  },
  {
    id: 5,
    title: ‘fifth’,
    value: 10,
    color: randomColor(),
  }
];

// now convert above data for pie chart

const pieGenerator = d3.pie<any, DataItem>().value(d => d.value);

Now, we can create new array from it as we want

const arcPathGenerator = d3.arc();

      const pieD = pie?.map?.((item, index) => {
        return {
          ...item?.data,
          arc: arcPathGenerator({
            innerRadius: size / 2.2,
            outerRadius: radius,
            startAngle: item.startAngle,
            endAngle: item.endAngle,
          }),
        };
      });

      return pieD;

Here, we have created arc from the pie data along with other donut data (title, value etc), and conditioned inner and outer radius according to selected arc

return (
    <View style={styles.wrapper}>
      <Svg width={size} height={size} viewBox={`0 0 ${size} ${size}`}>
        <G transform={`translate(${size / 2}, ${size / 2})`}>
          {arcs.map((item, index) => {
            return (
              <Path
                key={index}
                d={item?.arc}
                fill={item?.color}
                onPress={() => clickHandler(item, index)}
              />
            );
          })}
        </G>
      </Svg>
    </View>
  );

Map arcs data with Path with size props as above 👆🏻

Our simple donut chart is Ready 😎🍩

Further more we can add, arc selection to highlight specific arc of donut chart and show the percentage of that arc,

Create state for selected arc

const [selectedArc, setSelectedArc] = useState<object | undefined>(undefined);

Modify pieD variable’s logic as below

const arcPathGenerator = d3.arc();

      const pieD = pie?.map?.((item, index) => {
        return {
          ...item?.data,
          arc: arcPathGenerator({
            innerRadius:
              selectedArc?.id === item?.data?.id
                ? size / 2.2 + diffGap
                : size / 2.2,
            outerRadius:
              selectedArc?.id === item?.data?.id ? radius + diffGap : radius,
            startAngle: item.startAngle,
            endAngle: item.endAngle,
          }),
        };
      });

      return pieD;

And add onPress to Path and pass item to it

return (
   <Path
     key={index}
     d={item?.arc}
     fill={item?.color}
     onPress={() => clickHandler(item, index)}
   />
 );

And set item to selectedArc state

const clickHandler = (arc, i) => {
  setSelectedArc && setSelectedArc(prev => (prev?.id === arc?.id ? undefined : arc));
};

When we click on any arc we display it as selected and display its percentage center

Here’s the full source code of donut.tsx

import React, { useMemo, memo } from “react”;
import { View, StyleSheet } from “react-native”;
import { useTheme } from ‘@react-navigation/native’;

import { G, Path, Svg } from ‘react-native-svg’;
import * as d3 from ‘d3';

import { AppText } from ‘@components’;
import { modarateHeight } from ‘@utils/responsive’;
import { colors } from ‘@theme’

type DonutProps = {
  size: number;
  data: object[];
};

const diffGap = modarateHeight(0.3);

const Donut = ({ size, data }: DonutProps) => {

  const radius = Math.min(size, size) / 4

  const pie = useMemo(() => {
    if (data?.length > 0) {
      const pieGenerator = d3.pie<any, DataItem>().value(d => {
        return d.value;
      });
      return pieGenerator(data);
    }
  }, [data]);

  const arcs = useMemo(() => {
    if (pie?.length > 0) {
      const arcPathGenerator = d3.arc();

      const pieD = pie?.map?.((item, index) => {
        return {
          ...item?.data,
          arc: arcPathGenerator({
            innerRadius:
              selectedArc?.id === item?.data?.id
                ? size / 2.2 + diffGap
                : size / 2.2,
            outerRadius:
              selectedArc?.id === item?.data?.id ? radius + diffGap : radius,
            startAngle: item.startAngle,
            endAngle: item.endAngle,
          }),
        };
      });

      return pieD;
    }
  }, [radius, pie, selectedArc]);

  const clickHandler = (arc, i) => {
    setSelectedArc(prev => (prev?.id === arc?.id ? undefined : arc));
  };

  const component = () => (
    <View style={styles.wrapper}>
      <Svg width={size} height={size} viewBox={`0 0 ${size} ${size}`}>
        <G transform={`translate(${size / 2}, ${size / 2})`}>
          {arcs.map((item, index) => {
            return (
              <Path
                key={index}
                d={item?.arc}
                fill={colors?.[index]}
                onPress={() => clickHandler(item, index)}
              />
            );
          })}
        </G>
      </Svg>
      {selectedArc && (
        <AppText
          label={`${Math.abs(selectedArc?.value).toFixed(1)}%`}
          style={styles.label}
          medium
        />
      )}
    </View>
  );

  if (!arcs || arcs?.length <= 0) return null;
  return useMemo(component, dependancies)
}

export default memo(Donut);

const styles = StyleSheet.create({
    wrapper: {
      flex: 1,
      justifyContent: &#x27;center&#x27;,
      alignItems: &#x27;center&#x27;,
    },
    label: {
      position: &#x27;absolute&#x27;,
      color: colors.text,
    },
})

Happy coding 😊
